(1）油煙吸收率應大于95%采用同誑導流圍護裝置
(1) The absorption rate of oil fume shall be greater than 95%, and the same diversion enclosure shall be used
（2）圍護結構應配有鉸接式檢查門,以便于衛生清潔及觀察
(2) The enclosure shall be equipped with hinged inspection doors to facilitate sanitary cleaning and observation
（3）設備全部由不銹鋼制成所有聯結處為防水防蒸汽防油煙
(3) The equipment is all made of stainless steel, and all joints are waterproof, steam proof and oil smoke proof
（4）風罩嵌入吊頂內兩者之間設有不銹鋼裝飾板用厚度1.2mm的不銹鋼板制造易拆卸嵌入深度≥100mm
(4) The fan hood is embedded in the ceiling. There is a stainless steel decorative plate between them. It is made of 1.2mm thick stainless steel plate. It is easy to remove. The embedded depth is ≥ 100mm
（5）全部罩體用厚度大于1.0mm的不銹鋼板制造
(5) All covers are made of stainless steel plate with thickness greater than 1.0mm
（6）通風管用1.0鍍鋅板制成設有不銹鋼鐵風量調節閥
(6) The ventilation pipe is made of 1.0 galvanized sheet and equipped with stainless steel iron air volume regulating valve
（7）照明設備是防濺防水內凹型的分布于每1000mm距離并應將所有電線套于導管中用接駁箱連接照度裝置大于等于600lux采用芝光管燈,統一的電力接口
(7) The lighting equipment is splash-proof, water-proof and concave, distributed every 1000mm away, and all wires shall be sheathed in the conduit. The lighting device shall be connected with a junction box, and the illumination device shall be greater than or equal to 600lux. Energy-saving fluorescent tube lamp shall be used, and the uniform power interface shall be used
（8）風罩豎板帶有一體環繞的自排裝置排放槽易于清洗油煙蒸汽排放管為不銹鋼制并聯風罩的全自動自清潔裝置
(8) The vertical plate of the fan hood is equipped with an integrated self-cleaning device. The exhaust tank is easy to clean the oil fume and steam. The exhaust pipe is made of stainless steel and connected to the fan hood with a fully automatic self-cleaning device
This article is dedicated by Jinan smoke exhaust hood. For more information, please click: http://www.lishifudao.com Sincere attitude. We will provide you with comprehensive services. We will continue to offer you more relevant knowledge. Please look forward to it
